The 36-Series is Allegheny's largest industrial paper shredder — a 36″ (914 mm) chamber built for bulk, high-volume paper shredding at the highest sustained volume, from the 36-1000C through the heavy-duty 36-1000CHD at up to 200 HP, plus a particle-cut option.
| Model | Materials | Cut | Piece size | HP | Capacity | Discharge | Optional configurations |
|---|---|---|---|---|---|---|---|
| 36-1000C | Paper · cardboard | Strip-cut | 5/8″ (15.9 mm) | 100 / 125 HP | 5–7 tons/hr (4.5–6.4 t/hr) | External | Output conveyor · HLS-Tipper |
| 36-1000CHD | Paper · cardboard | Strip-cut (heavy-duty) | 5/8″ (15.9 mm) | 150 / 200 HP | 8–11 tons/hr (7.3–10.0 t/hr) | External | Output conveyor · Infeed conveyor · HLS-Tipper |
| 36-1000PC | Paper · cardboard · plastic · e-scrap (HDD/SSD) | Particle-cut | 1/2″ × variable (12.7 mm × variable) | 30 HP | On request | External | Output conveyor · Infeed conveyor · HLS-Tipper |
Standard cutter sizes shown — the approximate finished piece. Full specifications for the 36-1000C and 36-1000CHD are below; particle-cut capacity, dimensions and weight are available on request.
Also destroys e-scrap. The 36-1000PC particle-cut configuration also shreds hard drives and SSDs in bulk — see the Particle Cut line.
| Cutting assembly | 36″ (914 mm) |
| Capacity | 5–7 tons/hr (4.5–6.4 t/hr) |
| Horsepower | 100 HP or 125 HP |
| Voltage | 460 V, 3-phase, 60 cycle |
| Drive | Electric |
| Cutter type | Sawtooth |
| Cutter | 5/8″ (15.9 mm) |
| Dimensions | 126″ W × 166″ L × ~84″ H |
| Weight (approx.) | 18,000 lb (8,165 kg) |
| Color | Gray |
| Discharge type | External discharge |
| Cutting assembly | 36″ (914 mm) |
| Capacity | 8–11 tons/hr (7.3–10.0 t/hr) |
| Horsepower | 150 HP or 200 HP |
| Voltage | 460 V, 3-phase, 60 cycle |
| Drive | Electric |
| Cutter type | Sawtooth |
| Cutter | 5/8″ (15.9 mm) |
| Dimensions | 130″ W × 170″ L × ~90″ H |
| Weight (approx.) | 26,000 lb (11,793 kg) |
| Color | Gray |
| Discharge type | External discharge |
Note: Actual capacity and performance may vary depending on material properties, operating conditions, and available power supply. Specifications are subject to change without notice as part of our continuous product improvement program. Dimensions and weight exclude optional configurations.
